Blue Sea 8084 AC Main +6 Positions/DC Main +15 Positions Toggle Circuit Breaker Panel - White Switches
The 8084 AC Main +6 Positions/DC Main +15 Positions Toggle Circuit Breaker Panel is a high-quality electrical management solution designed specifically for marine and boating applications. Its robust construction and comprehensive feature set ensure reliable performance and safety for your vessel's electrical systems.
Features
- Includes a set of 30 common AC and 30 common DC labels for easy identification
- All AC and DC buses are pre-installed and fully pre-wired for quick setup
- Label backlighting is pre-installed for enhanced visibility in low-light conditions
- All indicator LEDs are pre-installed to provide real-time status updates
- Maximum panel amperage: 100 Amperes DC / 50 Amperes AC, suitable for high-demand marine applications
AC Features
- Reverse Polarity Indicating LED: Red LED alerts you to any reverse polarity issues, ensuring the safety of your AC systems
- Optional 4029 AC Isolation Cover: Ready for installation to provide additional protection and meet specific marine standards
- 9353, 0-150 Volt AC Voltmeter: Monitor your AC voltage levels accurately
DC Features
- 100 Amp C-Series Circuit Breaker: Provides robust main circuit protection and switching for your DC branch circuits
- 8003, 8-16 Volt DC Voltmeter: Keeps track of your DC voltage
- 8017, 0-100 Amp DC Ammeter: Measures the current flowing through your DC circuits
- Upgradeable to 24 Volts: Owner-upgradeable with the 8240, 18-32 Volt DC Voltmeter for enhanced flexibility
Specifications
| Attribute | Details |
|---|---|
| AC Positions | Main +6 |
| DC Positions | Main +15 |
| Voltage | 120V AC / 12V DC |
| Breaker Configuration | (1) 30A - (3) 15A AC Circuit Breakers (1) 100A - (9) 15A DC Circuit Breakers |
| Box Dimensions | 7"H x 15"W x 23"L |
| Weight | 8.6 lbs |
| UPC | 632085080846 |
*Combined AC/DC panels require an AC Insulating Cover to meet ABYC Standards.
Safety Warning
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit P65Warnings.ca.gov.
